Process description

STAGE 1

VRKP Steel Industries Bellary TMT Bars Manufacturing process

Virgin iron ore is purchased through government-routed auctions.

Thorough quality check of the raw material is done to look for impurities.

The iron ore is processed and reduced to sponge iron.

The sponge iron is quality checked and segregated as per grade.

STAGE 2

The sponge iron is converted to high quality billets in steel melting furnaces.

Continuous casting is performed and finally each billet is tested for quality.

The billets are directly fed to produce TMT bars.

Each bar is cut and shaped into different lengths for further processing.

STAGE 3

Each billet of 100 x100 mm is cut into the desired TMT bar size through a comprehensive reduction process.

All TMT bars are passed through a quenching process.

Bars of all sizes are checked for quality.

STAGE 4

The 'Ladle Refining Furnace' provides a superior grade to our TMT bars.

STAGE 5

Bars are stacked for dispatch.

The TMT Rebars are then customised for consumer consumption.

SPECIFICATION AND MATERIAL ANALYSIS

We use the highest quality of materials to ensure the highest quality of construction.
Our bars are durable, strong and have a low percentage of impurities.

Vision

Comparison of VRKP FE-500 TMT BAR and ISI standards

Properties/Composition Unit India (ISI:1786) VRKP TMT
Mechanical Or Physical Properties
Grade Unit Fe-500 Fe-500
Proof Stress N/mm2 500 min 500 min
Ultimate Stress N/mm2 565 min 565 min
Elongation % 12 min 12 min
Safety Factor Ratio 1.08 min 1.08 min
Chemical Properties (%)
Carbon % 0.30 max 0.25 max
Sulphur % 0.055 max 0.050 max
Phosphorous % 0.055 max 0.050 max
S+P % 0.105 max 0.105 max
Carbon Equivalent % 0.42 max 0.40 max
Si. % 0.10 min 0.18 min

VRKP 500 TMT is manufactured through a superior quality and controlled steel making process to diminish the levels of impurities and improve strength.

These impurities decrease the strength of steel in extreme hot and cold conditions. We ensure that these impurities are kept to their lowest levels, so as to ensure great construction.

Our Rebars are more ductile than any in the market today as they follow a unique process. With special use of chemistry and a post rolling treatment, they possess tremendous capacity to absorb energy beyond the regular yield limits. This makes them thoroughly earthquake-resistant. We achieve this by complete backward integration of steel making.

MATERIAL ANALYSIS AND WHY IT IS NECESSARY

Materials analysis is necessary to characterise and evaluate the quality and performance of the said materials. Through our analysis, we aim to effect change in expansive industries such as aerospace, automotive, nuclear, chemicals, oil and gas, polymers and plastics, packaging, adhesives, medical devices, textiles and apparel, building materials, electronics, composites, consumer products and non-material.

We want to give our customer the best. With our Material Analysis services, we ensure that the quality of your materials is top-notch, solve performance issues, and also support product development. We go the extra mile and even investigate failure issues by providing the information you need to understand your material’s composition such as - structural, mechanical, chemical and physical properties.
